hammer drive anchor

hammer drive anchor
hammer drive anchor

hammer drive anchor

SKU CA003 Category Tags , , , , ,

The Duojia Hammer Drive Anchor, also known as a Hammer-In Fixing, is a light-duty, easy-to-install fastener designed for quick and secure mounting on hollow base materials like plasterboard (drywall), hollow block, and plaster. Made from durable carbon steel and finished with a protective Yellow Zinc Plating (YZP), this anchor provides good corrosion resistance for indoor applications. Its simple, hammer-in design makes it an extremely convenient solution for home improvement, construction, and renovation projects where speed and efficiency are key.

GET A QUOTE

Product Details and Installation

This anchor is a two-piece, pre-assembled fastener designed for rapid installation. Its name comes directly from its installation method.

  • Mechanism: The anchor consists of two components:
    1. The Anchor Body: A cylindrical, slotted sleeve made of zinc alloy or steel with a low-profile flat head.
    2. The Drive Pin: A nail-like steel pin that is pre-inserted into the anchor body.
  • Installation Process:
    1. Drill a hole of the correct diameter through the plasterboard or hollow material.
    2. Gently tap the entire anchor assembly into the hole until the head of the anchor body is flush with the wall surface.
    3. Use a hammer to drive the pin into the anchor body. Continue hammering until the head of the pin is flush with the head of the anchor body.
    4. As the pin is driven in, it forces the slotted sides of the anchor body to expand and flare out behind the plasterboard, creating a secure and permanent grip.

Product Parameters

Parameter ItemSpecification Description
Product NameHammer In Plasterboard Fixing – YZP
Brand NameDuojia
Place of OriginHebei, China
MaterialCarbon Steel
Surface TreatmentYellow Zinc Plated (YZP)
Available SizesM6-M20
Strength Grades4.8, 8.8, 10.9, 12.9, A2-70, A4-70, A4-80 etc.
Measurement SystemMetric
ApplicationGeneral Industry, Home Improvement
CertificationsISO9001, ISO14001, ISO45001, SGS
Packaging OptionsSmall Pack + Carton + Pallet; Bag/Box with Pallet

Product Features

  • Extremely Fast Installation: The simple hammer-in design allows for rapid installation, significantly reducing labor time compared to screw-in anchors.
  • Good Corrosion Resistance: The Yellow Zinc Plating provides a durable finish that protects the carbon steel anchor from rust in typical indoor environments.
  • Flush Finish: The low-profile head of the anchor sits flush against the wall surface, providing a neat and unobtrusive fixing point.
  • Tamper-Resistant: Once the pin is fully driven in, the anchor is difficult to remove, making it a secure choice for permanent fixtures.
  • Ideal for Light-Duty Applications: It is perfectly suited for securing lightweight items to hollow walls where a quick and reliable fixing is needed.

Product Applications

The Hammer Drive Anchor is a versatile fastener for light-duty applications in hollow materials. Common uses include:

  • Electrical Fixtures: Securing electrical boxes, conduit clips, and junction boxes to drywall.
  • Interior Finishing: Fastening baseboards, trim, and wall-mounted brackets.
  • Home Decoration: Hanging lightweight shelves, pictures, and other decorative items.
  • Construction: Attaching drywall track and other light-duty framework to hollow block or plasterboard.
